Maintaining Airflow and Pressure Control Laminar Flow Hood

Technical Specifications:

Product Name: Laminar Flow Hood
Dimensions: 18009002600 (mm)
Cleanliness Level: Static Class 100 @ 0.3um (US Federal Standard)
Cabinet Material: SUS304 Stainless Steel
Average Face Velocity: 0.25～0.55m/s (adjustable in three levels), recommended 0.35m/s
HEPA Filters: 2 pcs, 78969369 (mm), efficiency 99.995%@≥0.3μm
Medium Efficiency Filters: 4 pcs, 75025021, efficiency 45%@≥0.5μm
Pre-filters: 4 pcs, 75025017, efficiency 40%@≥2.0μm
Note: Pre-filters should be replaced every 1-3 months, medium efficiency filters every 3-6 months, and HEPA filters generally
every year.
Replacement Guidelines:
* HEPA filters must be replaced when the differential pressure reaches 400Pa.
* Pre-filters must be replaced or cleaned when the differential pressure reaches 50Pa.
* Medium efficiency filters must be replaced or cleaned when the differential pressure reaches 80Pa.
Noise Level: ≤65db
Power Supply: 220VAC, 50HZ, 550W (excluding power consumption of sockets)

Key Features:

Replacement Guidelines:

FAQ:
