Pharmaceutical 30㎡ Area FFU Class 1K Prefab Cleanroom

Pharmaceutical 30㎡ Area FFU Class 1K Prefab Cleanroom
Pharmaceutical 30㎡ Area FFU Class 1K Prefab Cleanroom

Large Image :  Pharmaceutical 30㎡ Area FFU Class 1K Prefab Cleanroom

Product Details:
Place of Origin: China
Brand Name: GCC
Certification: QS/SC
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Plywood box
Delivery Time: 7-14 workdays
Payment Terms: T/T, L/C
Supply Ability: 1000set/ month

Pharmaceutical 30㎡ Area FFU Class 1K Prefab Cleanroom

Description
Keyword: Prefab Cleanroom Material: Stalinite/Stainless Steel/ Aluminum
Characteristic: Easy To Install Video Outgoing-inspection: Provided
Machinery Test Report: Provided After-sales Service Provided: Video Support
Highlight:

FFU class 1K Prefab Cleanroom

,

30m2 Area Prefab Cleanroom

,

FFU class 1K biological clean room



Prefab cleanrooms are essential to any manufacturing process where particulate contamination can affect the quality of goods produced. Prefab cleanroom through controlled air filtration, which lowers the possibility of product contamination or large particulate interference within critical process manufacturing.



Additionally, prefab clean room require positive pressure is continuously maintained while the cleanroom is operational. This process prevents contaminated air from flowing back within the clean air environment. This process allows clean filtered air to continuously flows from clean to less-clean spaces, allowing for continual air movement.



Level Of Airborne Particulate Cleanliness In Prefab Cleanrooms



Level Maximum Particles/m3 Equivalent
  ≥0.1 μm ≥0.2 μm ≥0.3 μm ≥0.5 μm ≥1 μm ≥5 μm
ISO 1 10b d d d d e
ISO 2 100 24b 10b d d e
ISO 3 1000 237 102 35b d e Class 1
ISO 4 10000 2370 1020 352 83b e Class 10
ISO 5 100000 23700 10200 3520 832 d,e,f Class 100
ISO 6 1000000 237000 102000 35200 8320 293 Class 1,000
ISO 7 c c c 352000 83200 2930 Class 10,000
ISO 8 c c c 3520000 832000 29300 Class 100,000
ISO 9 c c c 35200000 8320000 293000 Room Air



Specification Table



Area 15㎡ 30㎡ 50㎡ 100㎡
Material Aluminum frame/Baking steel plate/lnsulating glass window
FFU class 1-100 12pcs 24pcs 48pcs 96pcs
FFU class-1K 3pcs 6pcs 9pcs 18pcs
FFU class-10K 2pcs 4pcs 6pcs 12pcs
Speed (m/s) 0.45m/s ±20% 0.45m/s ±20%
Temperature (optional) 18-28°C
Humidity (opiional) 50-70% 50-70%
Illumination 400-800LUX
Power 2.4-7kw 4.8-10kw 9.6-19kw 19.2-30kw



Applications



GCC prefab cleanroom projects cover in pharmaceutical plants, laboratories, testing centers, dust free production workshops, precision machinery industry, hospitals, electronics factories, semiconductor factories, microelectronics workshops, electrical appliances workshops, etc.



Our Advantage



Gcc commitment is to provide our customers with the best products and services at affordable price and create better environment.
If you have any questions, please feel free to contact us. We will provide a best solution according to your require.
