FS209E 100Rank Laminar Flow Clean Bench

FS209E 100Rank Laminar Flow Clean Bench
FS209E 100Rank Laminar Flow Clean Bench

Large Image :  FS209E 100Rank Laminar Flow Clean Bench

Product Details:
Place of Origin: China
Brand Name: GCC
Certification: CE
Model Number: LCB
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: Plywood Box
Delivery Time: 7-14 Workdays
Payment Terms: T/T, L/C
Supply Ability: 50000Sets/Month

FS209E 100Rank Laminar Flow Clean Bench

Description
Product Name: Laminar Flow Tabletop Clean Bench Key Word: Clean Bench
Material: Steel Style: Tabletop Design
Quality Control: Delivery Inspection Video And Test Report After-Sales Service Provided: Online Support
Highlight:

FS209E 100Rank Laminar Flow Clean Bench

,

FS209E 100Rank tabletop laminar flow hood

,

FS209E 100Rank desktop laminar flow hood

Laminar Flow Tabletop Clean Bench

GCC tabletop laminar flow hood are engineered to provide the ideal particle-free, bacteria-free clean-air environment needed for laboratory work, testing, manufacturing, inspection, or pharmaceutical procedures. exclusive design innovations provide exceptional performance in the most demanding environments.



Applications



Applications benefiting from clean rooms, electronics assembly, semiconductors, pharmaceutical .aerospace and medical devices industries, mycology and food microbiology, plant and mammalian Cell culture.



Technical Parameter



Model

GCC -LFH

External Size

600×580×1060mm

Internal Size

580×520×610mm

Purification Rank

FS209E 100Rank

Rating Airflow

1800m³/h

Filtration Efficiency

More than 99.99%@0.3um H13-H14

Average Wind Speed

0.3-0.6m/s

Intensity Of Illumination

>300lx

Pressure Gauge

America Dwyer pressure watch 1 pcs

UV Light

1 pcs

Fluorescent Lamp

30Wx1

Material(Option)

1. Entirety S/S.

2. External is steel with power coated, Internal is S/S.

Power

450w

Noise

<65dB

Power supply

110V/ 60Hz 220V-240V AC 50Hz



Quality Control


Factory testing (all the sets you ordered):
All of equipment is individually factory tested for safety and performance in accordance with international Standards.
Each unit is shipped with a documentation outlining the tests undertaken and the unit’s individual results for each unit.
Factory test include:
--appearance testing
--functional test and visual inspection
--air velocity testing
--noise testing



Suggestion



1. Pre-filter: each one should be replacement in each 6 month, but it can refresh no more three times.



2. HEPA filter: each one should be replacement in each half and one years.
