The Horizontal Steam Sterilizer (Autoclave) is a professional-grade, large-capacity sterilization device that utilizes high-temperature saturated steam technology to completely eliminate bacteria, viruses, and spores, ensuring absolute sterility for medical instruments, laboratory equipment, pharmaceutical devices, and food packaging.
The horizontal design offers larger capacity and easier loading, making it particularly suitable for hospital sterilization centers, pharmaceutical factories, food processing plants, and research institutions that require high-volume, efficient sterilization.
Features
✅ Spacious Sterilization Chamber – Available in capacities ranging from 100L to 1500L to meet various batch requirements.
✅ High-Efficiency Sterilization – 121°C~134°C high-temperature steam with strong penetration for thorough sterilization.
✅ Intelligent Control System – 7-inch color touchscreen with preset sterilization programs (for instruments, fabrics, liquids, etc.).
✅ Multiple Safety Protections – Pressure safety valve, temperature sensor, automatic door lock, water shortage protection, and more.
✅ Energy-Saving & Eco-Friendly – Steam recycling system reduces energy consumption by over 30%.
✅ Durable Construction – 316L stainless steel sterilization chamber, corrosion-resistant, with a service life of over 10 years.
✅ Optional Functions – Vacuum drying, data printing, remote monitoring, etc.
Specifications
| Model |
Capacity (L) |
Temperature Range (°C) |
Working Pressure (MPa) |
Power (kW) |
Sterilization Time (min) |
Chamber Dimensions (mm) |
Overall Dimensions (mm) |
| WS-100L |
100 |
105~134 |
0.22 |
9 |
15~60 |
400×500×500 |
900×700×1200 |
| WS-300L |
300 |
105~134 |
0.22 |
15 |
15~60 |
600×700×700 |
1200×900×1500 |
| WS-500L |
500 |
105~134 |
0.22 |
24 |
15~60 |
800×800×800 |
1500×1100×1800 |
| WS-1000L |
1000 |
105~134 |
0.22 |
36 |
15~60 |
1000×1000×1000 |
2000×1300×2000 |
Note: Custom larger capacities and special functions are available upon request.
FAQ
Q1: What's the difference between horizontal and vertical sterilizers?
-
Horizontal: Larger capacity (100L+), side-loading, ideal for high-volume continuous sterilization.
-
Vertical: Smaller capacity (50-200L), top-loading, suitable for small batches or laboratory use.
Q2: What if items are wet after sterilization?
Q3: Can liquid culture media be sterilized?
-
Yes, but the liquid sterilization program must be selected, and heat-resistant, breathable containers should be used.
Q4: What are the required supporting conditions?
-
Power supply: 380V/50Hz (for high-power models).
-
Water source: Purified or distilled water.
-
Steam source: Built-in steam generator or connected to a boiler.
Q5: How to perform daily maintenance?
-
Daily: Clean the chamber walls and check water levels.
-
Weekly: Inspect sealing rings and clean filters.
-
Annually: Comprehensive inspection by professionals.
Q6: What safety measures does the equipment have?
-
Automatic pressure release in case of overpressure.
-
Automatic power cutoff in case of overheating.
-
Door lock prevents operation if not properly closed.
-
Water shortage alarm.
Q7: What certifications are required?
-
Medical use: CE, FDA, ISO 13485.
-
Pressure vessel: ASME or PED certification.
-
In China: Special Equipment Manufacturing License.
Why Choose Our Horizontal Sterilizer?
✔ 20 years of professional manufacturing experience, ensuring quality.
✔ CE/FDA and other international certifications, globally applicable.
✔ Customization services available to meet special requirements.
✔ 24/7 technical support, worry-free after-sales service.
